Item: 49127
Model: HOOD-110-USA
Item: 49127
Model: HOOD-110-USA
Water Hardness: 2 - 8 °F
Rinsing Temperature (Set): 185 °F (85 °C)
Tank Capacity: 31.72 Qt. (30 L)
Tank Heating Element: 2940 W
Tank Temperature (Set): 160 °F (71 °C)
Booster Capacity: 10.64 Qt. (10 L)
Booster Heating Element: 9800 W
Inlet Water Pressure 25 - 95 PSI: (170-620 kPa)
Power: 10.92 kW
Amperage: 46.3 A
Electrical: 220-240V / 60 Hz / 1 Ph
Water Consumption / Cycle (water pressure 200kpa): 3.16 Qt. (3 L)
Washing Cycles: 1 (120) | 2 (180)
Water Supply 131 °F Racks /H (*)(1): 30 | 20
Water Supply 50 °F Racks /H (*)(1): 30 | 20
Pump Power: 1120 W (664 Qt./628 L per minute***)
Drain Pump: 43 W hMAX 31.5” (800 mm) (43.12 Qt. / 40.8 L***)
Noise: 66430.7 dB(A)
Rack Equipment: (2) Plastic Plates Basket | (1) Large Mesh Glass Basket | (2) Cutlery Basket
Rack Dimensions: 20” x 20” (508 x 508 mm)
Crockery Dimensions Plates: 16.25” (412 mm) dia. | Tray Max: Gastronorm 1/1 (20.87” x 12.75” / 530 x 323 mm)
Net Weight: 220 lb. (100 kg.)
Net Dimensions (WDH): 28.37” x 28.93” x 56.87” (720 x 734 x 1444 mm) | 74” (1881 mm) Height (open hood)
Gross Weight: 256 lb. (116 kg.)
Gross Dimensions (WDH): 30” x 33” x 59” (760 x 840 x 1500 mm)
(*) Standard Thermostop
(1) In case of cold water supply and/or continuous washing, the rinse-water heating process might take more time than usual, until the proper rinse temperature is reached. For this reason, the wash-cycle total timing might result longer than set.
(***) Maximum Flow Rate
